Valves · Needle Valves
Forged Body Tube End
The forged-body needle valve in a tube-end configuration, taking compression tube connections instead of threads. Suits instrument hook-ups piped in tube throughout, where a threaded joint would add an unnecessary leak path between the take-off and the instrument.
- Product ID
- VAL-NV-02
- Available Part Nos.
- 3
- Category
- Needle Valves
PRODUCT IDVAL-NV-02
3PART NO. ROWS
01SIZE
02T' Tube OD
03L
04H Open
Needle Valves
Product overview
Forged Body Tube End is part of Parflow's needle valve range for flow control, isolation, venting, and instrument connections.
Needle valves support controlled flow, isolation, venting, and instrument connections across the published end-connection configurations.
Forged Body Tube End is available in 3 published Part No. configurations across 1 specification table. Published fields include SIZE, T' Tube OD, L, H Open.
Technical data
Specifications
3 published Part No. configurations
NEEDLE VALVE
3 Part Nos.
| Part No. | SIZE | T' Tube OD | L | H Open | Cart status |
|---|---|---|---|---|---|
| PNV-FB-S-4TT-T | 1/4" | 1/4" | 2.55 | 2.28 | |
| PNV-FB-S-6TT-T | 3/8" | 3/8" | 2.55 | 2.28 | |
| PNV-FB-S-8TT-T | 1/2" | 1/2" | 2.77 | 2.44 |
