Forged Body Female End
A needle valve with a forged one-piece body and female threaded connections at both ends. The forged body carries pressure without a welded seam, and the tapered stem gives fine, repeatable throttling down to a metal-to-metal shut-off. Used to isolate and regulate gauges, transmitters and sample lines on threaded take-offs.
- Product ID
- VAL-NV-01
- Available Part Nos.
- 6
- Category
- Needle Valves
Product overview
Forged Body Female End is part of Parflow's needle valve range for flow control, isolation, venting, and instrument connections.
Needle valves support controlled flow, isolation, venting, and instrument connections across the published end-connection configurations.
Forged Body Female End is available in 6 published Part No. configurations across 1 specification table. Published fields include SIZE, T' NPT(F), D, L.
Specifications
6 published Part No. configurations
NEEDLE VALVE
6 Part Nos.
| Part No. | SIZE | T' NPT(F) | D | L | H Open | Cart status |
|---|---|---|---|---|---|---|
| PNV-FB-S-2FF-T | 1/8" | 1/8" | 0.79 | 1.97 | 2.28 | |
| PNV-FB-S-4FF-T | 1/4" | 1/4" | 0.79 | 1.97 | 2.28 | |
| PNV-FB-S-6FF-T | 3/8" | 3/8" | 0.98 | 1.97 | 2.44 | |
| PNV-FB-S-8FF-T | 1/2" | 1/2" | 1.26 | 2.52 | 2.87 | |
| PNV-FB-S-12FF-T | 3/4" | 3/4" | 1.42 | 2.52 | 3.07 | |
| PNV-FB-S-16FF-T | 1" | 1" | 1.69 | 3.31 | 3.94 |
